VECTOR
NEXT

Full specifications
Dimensions
Specs
Models
Parameters VECTOR NEXT 7.6 VECTOR NEXT 7.1 CNG/LPG
Length/Width/Height, mm 7645/2445/2915 7200/2445/2915
Door number/width, mm 2/650 2/6502/650
Ceiling height in passenger compartment, mm 19501950
Body type Semi-integral, wagon-typeIntegral, wagon-type
Min. turning radius, m 6,758,1
Unladen/ fully loaded weight, kg 6150...6270/100005600…6200/10000
Front/rear axle load, kg 3500/6500 3500/6500
Total passenger capacity (including seats) 43 (25+1), 50 (21+1), 53 (17+1)39 (21+1); 43 (18+1)
Capacity of fuel tank/gas cylinders, l 9595, 360 360 (5 pcs. 62 l each and 1 pc. 50 l) or 190 (2 pcs. 95 l each)
Chassis/axle C40R13, produced by GAZGAZ
Steering gear Integral type, hydraulic power steeringIntegral type, hydraulic power steering
Braking system Disk brake mechanisms with automatic brake clearance adjustment, pneumatic drive of brake mechanisms, with АВS, ASRDisk brake mechanisms with automatic brake clearance adjustment, pneumatic drive of brake mechanisms, with АВS, ASR
Ventilation Natural, through side windows and roof hatchesNatural, through side windows and roof hatches
Heating system Independent, autonomous liquid starting preheater and 3 passenger compartment heatersFront heater and 3 passenger compartment heaters
Tyres 245/70 R19,5245/70 R19,5
